· They are generally used to control a maximum level.
· Manufacted in SS AISI304
· Float: Cylindrical ø17x47 mm
· Density: 0,7 g/cm³
· Temperature: -40..+125 ºC
· Pressure: 5 kg/cm²
· Protection: IP67
· They have a single contact for maneuver.
· Contact: (NO) 50W/VA-0,5A/230VAC
· By reversing the position of the float, it also reverses the state of the contact.
It remains to be decided
Select a product to display its configuration data
Reference
aaaa
CodeWeight (kg)Dimensions (mm)
Delivery time
The delivery time is expressed in working days. It... [Know more]
· They are generally used to control a maximum level.
-Technical data
· Assembly from inside the tank
· Process connection: Nipple. 1/8" G
· Electrical connection: 2 PVC cables, 300 mm
· Length: 94 mm
+ Documentation
· Data sheet
· Declaration of conformity CE
· User manual
· 3D file [.ZIP]
· Installation and application tips
+Ordering
· Use the same reference of each model for ordering.
· Check that the conditions of pressure and temperature of your installation matches with the ones supported by the chosen model.
· If you have questions about the behavior of SS in front to the liquid you want to control, see the Table of chemical resistance.
+Table of chemical resistance
Substance
Other names
+Related products
PSPS -DSPS -SSPS
· Weak contacts protection
· To be used in instruments with potential free contacts
PSMS -DSMS
· Contact amplifier with two independent inputs
· To be used in devices with potential free contacts
PSIA -DSIA
· Control for detection of turbulences in liquids
· Delay to the level detection
· Control differential maximum and minimum levels by timing
· To be used in devices with potential free contacts
+
It remains to be decided
Select a product to display its configuration data
Reference
aaaa
CodeWeight (kg)Dimensions (mm)
Delivery time
The delivery time is expressed in working days. It... [Know more]
· They are generally used to control a maximum level.
-Technical data
· Assembly from outside the tank
· Process connection: Nipple. 1/2" NPT
· Electrical connection: 2 PVC cables, 300 mm
· Longitud: 109 mm
+ Documentation
· Data sheet
· Declaration of conformity CE
· User manual
· 3D file [.ZIP]
· Installation and application tips
+Ordering
· Use the same reference of each model for ordering.
· Check that the conditions of pressure and temperature of your installation matches with the ones supported by the chosen model.
· If you have questions about the behavior of SS in front to the liquid you want to control, see the Table of chemical resistance.
+Table of chemical resistance
Substance
Other names
+Related products
PSPS -DSPS -SSPS
· Weak contacts protection
· To be used in instruments with potential free contacts
PSMS -DSMS
· Contact amplifier with two independent inputs
· To be used in devices with potential free contacts
PSIA -DSIA
· Control for detection of turbulences in liquids
· Delay to the level detection
· Control differential maximum and minimum levels by timing
· To be used in devices with potential free contacts
+
It remains to be decided
Select a product to display its configuration data
Reference
aaaa
CodeWeight (kg)Dimensions (mm)
Delivery time
The delivery time is expressed in working days. It... [Know more]
· They are generally used to control a maximum level.
-Technical data
· Assembly from outside the tank
· Process connection: Nipple. 1/2" NPT
· Electrical connection: Connector Mini DIN43650
· Length: 109 mm
+ Documentation
· Data sheet
· Declaration of conformity CE
· User manual
· 3D file [.ZIP]
· Installation and application tips
+Ordering
· Use the same reference of each model for ordering.
· Check that the conditions of pressure and temperature of your installation matches with the ones supported by the chosen model.
· If you have questions about the behavior of SS in front to the liquid you want to control, see the Table of chemical resistance.
+Table of chemical resistance
Substance
Other names
+Related products
PSPS -DSPS -SSPS
· Weak contacts protection
· To be used in instruments with potential free contacts
PSMS -DSMS
· Contact amplifier with two independent inputs
· To be used in devices with potential free contacts
PSIA -DSIA
· Control for detection of turbulences in liquids
· Delay to the level detection
· Control differential maximum and minimum levels by timing
· To be used in devices with potential free contacts
+
It remains to be decided
Select a product to display its configuration data
Reference
aaaa
CodeWeight (kg)Dimensions (mm)
Delivery time
The delivery time is expressed in working days. It... [Know more]
· They are generally used to control a maximum level.
-Technical data
· Assembly from outside the tank
· Process connection: Nipple. 1/2" NPT
· Electrical connection: Connector M12 (IP67)
· Length: 109 mm
+ Documentation
· Data sheet
· Declaration of conformity CE
· User manual
· 3D file [.ZIP]
· Installation and application tips
+Ordering
· Use the same reference of each model for ordering.
· Check that the conditions of pressure and temperature of your installation matches with the ones supported by the chosen model.
· If you have questions about the behavior of SS in front to the liquid you want to control, see the Table of chemical resistance.
+Table of chemical resistance
Substance
Other names
+Related products
PSPS -DSPS -SSPS
· Weak contacts protection
· To be used in instruments with potential free contacts
PSMS -DSMS
· Contact amplifier with two independent inputs
· To be used in devices with potential free contacts
PSIA -DSIA
· Control for detection of turbulences in liquids
· Delay to the level detection
· Control differential maximum and minimum levels by timing
· To be used in devices with potential free contacts
